Maurer, B. W., Green, R. A., Cubrinovski, M. & Bradley, B. A. (2015). Assessment of CPT-based methods for liquefaction evaluation in a liquefaction potential index framework. Géotechnique 65, No. 5, 328–336, http://dx.doi.org/10.1680/geot.SIP.15.P.007. The X-axis labels in Figs 8(a) and 8(b) were incorrect; the corrected figure appears below.
Fig. 8
Comparison of LPI model prediction errors at each investigation site, as computed by: (a) R&W98 plotted against MEA06; (b) R&W98 plotted against I&B082; (c) MEA06 plotted against I&B082
Fig. 8
Comparison of LPI model prediction errors at each investigation site, as computed by: (a) R&W98 plotted against MEA06; (b) R&W98 plotted against I&B082; (c) MEA06 plotted against I&B082
